Audit Trail & Webhook Events

This section documents the platform's observability and event-driven architecture. It covers the immutable audit trail for user actions, the platform event bus for internal reactivity, the webhook subsystem for external integrations, and the automation of evidence collection and risk management.

Platform Audit Trail

The platform implements a unified audit trail via the AuditTrailMiddleware. This middleware captures every authenticated API request and persists it to an immutable MongoDB collection named event_bus_audit_log. This system provides compliance-ready logs that answer who did what, when, and with what outcome.

AuditTrailMiddleware Implementation

The middleware operates as a BaseHTTPMiddleware within the FastAPI pipeline. It classifies actions, redacts sensitive data, and performs asynchronous background writes to minimize latency.

• Action Classification: Uses the _classify_action function to map HTTP methods and path patterns to human-readable strings (e.g., POST /api/auth/login becomes user.login).
• Recursive Body Redaction: The _redact_body function recursively traverses request bodies to scrub fields like password, secret, token, api_key, and mfa_token. This prevents sensitive credentials buried in nested objects (e.g., within configuration payloads) from leaking into the audit store.
• Performance: To prevent blocking the response, the database write is scheduled as an asyncio.create_task after the response has been generated.
• Exclusion Rules: Noisy paths (e.g., /api/health, /api/sse/) and standard GET requests (except for reports/exports) are excluded to reduce log volume.

Audit Logging Data Flow

sequenceDiagram
    participant C as "Client"
    participant M as "AuditTrailMiddleware"
    participant A as "AuthService"
    participant R as "Route Handler"
    participant DB as "MongoDB (event_bus_audit_log)"

    C->>M: "HTTP Request (POST /api/risks)"
    M->>A: "get_user_from_session()"
    A-->>M: "User (request.state.user)"
    M->>M: "_classify_action() -> 'risk.post'"
    M->>M: "_redact_body(request_payload)"
    M->>R: "call_next(request)"
    R-->>M: "Response (201 Created)"
    Note over M,DB: "Async background task"
    M->>DB: "insert_one(audit_doc)"
    M-->>C: "HTTP Response"

Platform Event Bus (Internal)

The EventBus is the central nervous system for cross-module reactivity, utilizing Redis Pub/Sub for real-time delivery and MongoDB for persistence.

Event Architecture

• Event Types: Canonical constants are defined in EventTypes, covering SCAN_COMPLETED, FINDING_CREATED, SLA_BREACHED, and COMPLIANCE_DRIFT_DETECTED.
• Subscribers: The event subscribers module registers handlers that route events to notifications (Email/Slack/Teams), integration tickets (Jira), and real-time SSE streams.
• SSE Real-time Stream: The stream_platform_events route allows frontend clients to subscribe to specific channels (e.g., ?channels=scan,finding) for live updates.

Webhook Security & Inbound Ingestion

The platform accepts scan results from external tools via secure webhook endpoints.

Webhook Security Schemes

The WebhookSecurityService supports two versions of HMAC authentication to ensure integrity and prevent replay attacks:

Feature	v1 (Legacy)	v2 (Current)
Location	Query Parameters (sig, ts)	Headers (X-Webhook-Signature, X-Webhook-Timestamp)
Body Binding	No (Vulnerable to substitution)	Yes (HMAC includes SHA256 of body)
Replay Protection	WebhookReplayCache (5 min TTL)	WebhookReplayCache (5 min TTL)

• v2 Signature Logic: The signature is computed as HMAC(secret, "v1:timestamp:scan_id:tool_name:body_hash") where the body hash is a SHA256 hexdigest of the raw bytes.
• Replay Protection: The WebhookReplayCache stores (timestamp, signature) pairs to prevent the same signature from being used twice within the TTL window.
• Ingestion: Validated payloads are passed to the external_scanner.receive_scan_result for processing.

Evidence Automation & Risk Exceptions

The platform automates the GRC lifecycle by wiring evidence collection to platform events and providing formal risk exception workflows.

Evidence Auto-Trigger Service

The EvidenceAutoTriggerService eliminates manual evidence collection by reacting to EventTypes.

• Scan Completion: Triggers on_scan_completed, which delegates to specific collectors (CSPM, K8s, Container, etc.) based on the scan_type.
• Freshness Monitoring: A weekly Celery task check_evidence_freshness uses _is_evidence_fresh to identify expiring evidence and alert users.

Risk Exception & KRI Monitoring

• Risk Exceptions: The RiskExceptionService manages the lifecycle of suppressed findings, including creation, admin approval, and expiration tracking.
• KRI Monitoring: The KRIMonitoringService evaluates Key Risk Indicators (e.g., critical_vuln_count, sla_breach_rate) against thresholds and emits RISK_THRESHOLD_BREACHED events when limits are crossed.

Entity Space Mapping

graph TD
    subgraph "Core Security (Audit/Webhook)"
        ATM["AuditTrailMiddleware"]
        WSS["WebhookSecurityService"]
        WRC["WebhookReplayCache"]
    end

    subgraph "Event-Driven Automation"
        EB["EventBus"]
        EATS["EvidenceAutoTriggerService"]
        KRIS["KRIMonitoringService"]
    end

    subgraph "Data Store (MongoDB)"
        EBAL["event_bus_audit_log"]
        KS["kri_snapshots"]
        RES["risk_exceptions"]
    end

    ATM --> EBAL
    EB -- "persists" --> EBAL
    WSS --> WRC
    EATS -- "subscribes" --> EB
    KRIS -- "snapshots" --> KS
    KRIS -- "publishes" --> EB

---
